Xaar Irix Core 80 L Printhead - XP12800071

Riferimento: XP12800071

Xaar Irix Core 80 L Printhead - XP12800071

This item is genuineXaar Irix Core 80 L Printhead - XP12800071. All orders are shipped promptly and come with a 100% satisfaction guarantee.

198,00 $

In magazzino

In saldo!

Riferimento: KOPPRHW-KYCR-0024

Marca: Kyocera

Brand New Kyocera KJ4A‑TL Printhead – Original Sealed Factory Packaging

This item is an original Kyocera KJ4A-TL Printhead, low prices, fast delivery, All products are 100% Guarantee.

2.398,00 $

In magazzino

Tutte le migliori vendite

In saldo!

Toshiba Tec CE4M Printhead

Name: Toshiba Tec CE4M Printhead
Brand: Toshiba
SKU: KOPPRHW-TSHB-0024
Price: 312.00 USD
Availability: InStock

Riferimento KOPPRHW-TSHB-0024

Marca Toshiba

This item is an original Toshiba Tec CE4M Printhead, low prices, fast delivery, All products are 100% Guarantee.

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Descrizione
Dettagli del prodotto

Descrizione

The Toshiba TEC CE4M is a grayscale industrial printhead built for UV-curable and oil-based pigment inks, with 636 active nozzles, 16 gray levels, 5–35 pl drop volume, and a native 150 dpi up to 300 dpi max output.

Buyer quick evaluation

Best fit: UV flatbed, labels, packaging, and other industrial printing where stable jetting and fine detail matter.
Strengths: high nozzle density, grayscale control, and water-circulation thermal control for stability.
Practical limits: it is not a general-purpose office head; it is designed for specialized industrial systems and ink sets.
Replacement note: one supplier says CE4M replaces the discontinued CE4W1, which can matter for compatibility checks.

Key specs

Item	Toshiba TEC CE4M
Technology	Multi-drop grayscale micro-piezo
Active nozzles	636
Print width	53.6–53.7 mm
Grayscale levels	16
Native resolution	150 dpi
Max resolution	300 dpi
Drop volume	5–35 pl
Firing frequency	2.8–28 kHz
Weight	148 g
Dimensions	85 x 70 x 23 mm

Comparison for purchasing

Buy if you need	CE4M is a good choice when...	Consider another head when...
UV flatbed / industrial graphics	You need UV or oil-based pigment compatibility and grayscale control	You need a lower-cost, non-industrial, or office-style head
Image quality	You want smoother shading and better dot control from 16 gray levels	You only need simple binary printing
Production stability	You want thermal control and 4 ink inlet ports for a more controlled setup	Your printer platform cannot support water-circulation or waveform settings
Speed vs detail	You want a balance of detail and throughput in an industrial system	You need very high-resolution photo output or a different ink chemistry

Purchase checks

Before buying, confirm the printer board, waveform, head ID, ink system, and physical mounting match your machine; one supplier explicitly notes the head is shipped with head ID, voltage, and waveform information. Also verify your ink compatibility claim against your actual ink type, since listed compatibility is mainly UV-curable and oil-based pigment ink. For a replacement purchase, matching the discontinued CE4W1 lineage may matter if your printer was originally configured for that head.

Decision shortcut

Choose the CE4M if your priority is industrial UV/oil printing, stable jetting, and grayscale image quality. Skip it if you are not sure about firmware/waveform compatibility, because that is the most common reason a replacement head underperforms even when the specs look right.
