Xaar 2002 Advanced GS12 Printhead

Designed to deliver exceptional 720dpi print resolution quality and performance across a range of applications, the new Xaar 2002 Advanced GS12 Printhead also delivers visibly improved colour uniformity across the width of the printhead.

Multiple technologies unique to Xaar ensure continuous and reliable printing in single-pass operation, maximising production output, minimising production interruptions and reducing the need for operator intervention

Using drop in printhead alignment, mechanical tolerance improvements allow the printheads to be dropped into the printbar more easily. Therefore set-up time is quicker, printhead replacement is faster and printer uptime is maximised.

Product Specifications

• Fluid base : Solvent, UV, Oil
• Subdrop volume* (pL) : 6 12 40
• Maximum firing frequency (up to) (kHz) :  36 36 24
• Nozzle density (nozzles per inch) : 720
• Print swathe width (mm) : 70.52
• Dimensions (mm) : 132 x 50 x 105

* Dependent on ink used and system integration
