Konica KM HS1000 Printhead

The Konica Minolta KM HS1000 printhead is a piezo drop-on-demand industrial inkjet printhead designed for high-speed single-pass printing. It features 1,024 nozzles arranged in 4 lines of 256, a 30 picoliter droplet size, 360 dpi native resolution, and a maximum drive frequency of 27 kHz.

Product Details

• Model: Konica KM HS1000.
• Type: Piezo Drop-on-Demand printhead.
• Nozzles: 1,024 total, arranged 256 x 4 lines.
• Droplet size: 30 pl.
• Native resolution: 360 dpi / 360 npi.
• Print width: 72 mm.
• Max firing frequency: 27 kHz.
• Drive voltage: 13 ±3 V.
• Ink compatibility: UV, oil, and solvent inks depending on system setup.

Compatibility

This printhead is commonly referenced as a replacement for the Konica Minolta KM1024i LHE platform, and supplier compatibility lists also include systems such as Agfa Anapurna models, Allwin UV models, Docan H1000, Flora HJ 5000UV, JHF Vista series, and others.

Important Disclaimer

Compatibility is not guaranteed for every printer using a KM1024i-style head. The HS1000 may require correct head cables, driver electronics, firmware support, ink type, and installation procedures, so please verify fitment with your printer manufacturer or technician before purchase.

Condition Disclaimer

Item is brand new in original factory packaging. Packaging may show normal shelf or shipping wear, but the product itself has not been used or installed

Buyer is responsible for verifying compatibility with their specific printer model and controller before purchase. If you are unsure, please message us with:

• Printer brand and model
• Current printhead model number (as printed on the head or in the manual)
• Ink type you are using (UV / solvent / oil-based)
• We will do our best to advise, but final compatibility verification rests with the buyer.

Condition & Packaging

• Condition: New
• Packaging: Factory sealed in original Konica Minolta packaging
• Handling: Do not open the printhead package until you are ready to install. Avoid touching the nozzle plate or electrical contacts. Store in a cool, dry place, away from direct sunlight and extreme temperatures.

Shipping

• Handling Time: We ship within [1–2] business days after cleared payment.
• Shipping Service: Shipped via FedEx / DHL / Local courier with tracking.
• Packaging: Printhead is packed securely with protective materials to prevent damage during transit.
• Combined Shipping: We offer combined shipping on multiple items. Please message us before payment for a revised invoice if you are purchasing more than one item.
• International Shipping: Available, shipped via FedEx / DHL / Local courier with tracking. Import duties, taxes, and customs charges are the buyer’s responsibility and are not included in the item price or shipping cost.

Returns

• Return Window: Returns accepted within [14 / 30] days of delivery.
• Condition for Return: Item must be unused, unopened, and in original factory-sealed packaging. Once the printhead packaging is opened or the head is installed, it cannot be returned unless it is proven to be dead on arrival (DOA) and not damaged by improper handling or installation.
• Return Shipping: Buyer pays return shipping unless the item is not as described or is DOA and confirmed by us.
• Refund: Refund issued for the item price once the returned item is received and inspected. Original shipping charges are non-refundable unless the return is due to our error.

Please contact us before initiating a return so we can provide instructions and, if applicable, an RMA number.

Warranty

• Seller Warranty: This item is sold as new, factory sealed. We do not provide an additional seller warranty beyond the return policy described above.
• Manufacturer Warranty: Any manufacturer warranty is subject to Konica Minolta’s policies and may require proof of purchase from an authorized distributor. We are [an authorized / not an authorized] Konica Minolta distributor – please message us if you have specific warranty questions.
• DOA Policy: If the printhead is confirmed dead on arrival (no electrical shorts caused by the user, proper installation, and compatible electronics), we will replace or refund according to our return policy. Damage caused by incorrect installation, incompatible electronics, wrong ink, static discharge, or physical damage is not covered.

Important Handling & Safety Notes

• Do not open the printhead until you are ready to install it.
• Follow your printer manufacturer’s installation and priming procedures exactly.
• Ensure your ink system, temperature settings, and waveforms are configured for the KM HS1000.
• Avoid touching the nozzle plate, filter, or electrical contacts.
• Store in a clean, dry environment, away from dust, direct sunlight, and temperature extremes.
