Konica KM512 MNX Printhead

The Konica KM512 MNX printhead is a high-resolution inkjet printhead featuring 512 nozzles with a native resolution of 360 dpi. It operates using on-demand piezoelectric technology and produces droplets of approximately 14 picoliters. The printhead supports both solvent and oil-based inks, making it versatile for various industrial printing applications.

Key specifications at a glance

• Nozzles: 512 total (typically 256 per channel; 360 dpi native resolution).
• Droplet size: 14 picoliters (MN/14PL variants).
• Print width: approx. 36.1 mm (per head).
• Firing frequency: around 12.8 kHz.
• Ink compatibility: Oil-based, solvent, and UV inks; heater usually not integrated (some variants include a heater).
• Operating mode: Binary and 4-level grayscale capable; supports variable drop size without extra heads.
• Heater: Some models include integrated heater (KM512 MNX/14PL with heater variants exist) — verify per unit.
• Origin: Japan-made; warranty on manufacturer/ reseller pages.

    Common names / variants

KM512 MN, KM512 MNX, KM512 MN14PL, KM512 MH (heater variant) – differences mainly in heater presence, drop size options (14pl, 42pl, etc.), and compatibility with certain inks or printers.

    Ink compatibility notes

Suitable for oil-based, solvent, and UV inks; not all variants are appropriate for varnish or white inks on all systems (e.g., some Agfa Anapurna configurations require different head types).

    Compatibility and printer systems

Widely used across diverse printer brands and systems (e.g., Agfa, Allwin, DGI, HP, MYJET, etc.), but compatibility is model/version specific. Confirm exact variant (MNX vs MN, presence of heater, 14pl vs 42pl) with the supplier or datasheet before purchase.

    Warranty and support

Manufacturer warranty, the item is new/original and includes waveform data where applicable.

    What to check before buying

• Model match: Ensure you’re buying KM512 MNX/14PL or the exact variant your printer requires; mismatches can lead to non-function or voided warranties.
• Heater option: Decide if you need an integrated heater (some models do) based on your ink type and curing process.
• Ink compatibility: Confirm your intended ink type (oil-based, solvent, UV) aligns with the head’s supported inks.
• Return policy: Many suppliers restrict returns once installed; check packaging integrity, compatibility, and whether exchanges are allowed if incorrect or defective.
• Cables & installation: Some sellers recommend replacing head cables during installation; plan for professional installation to avoid damage.

    Pros and limitations

• Pros: High nozzle count enables fast in-line production; supports grayscale for smoother gradients; versatile ink compatibility (oil/solvent/UV).
• Limitations: Narrow print width per head; potential non-return constraints post-installation; variant-specific heater and waveform data requirements; troubleshooting may require exact matching head model and firmware/waveforms.

    Buying steps (quick)

• Step 1: Confirm your printer model and required KM512 variant (MN, MNX, 14PL, with/without heater).
• Step 2: Verify ink compatibility and any heater needs with the supplier/dactory datasheet.
• Step 3: Check warranty terms and return policy; ensure the item is new and includes necessary waveform data if required.
• Step 4: Inspect packaging upon delivery; if damaged, report immediately per the seller’s policy.
• Step 5: Have a professional install; consider replacing head cables if recommended by the supplier.

    Quick pros/cons table

• Pros: High resolution, grayscale capability, versatile ink compatibility, robust Konica build.
• Cons: Variant-specific compatibility; strict installation/return policies; potential need for matching head cables and firmware; heater differences across variants.

    Quick caveats

Always verify the exact model and electrical/firmware compatibility with your printer before ordering; post-purchase returns can be restricted if the head is installed or if the packaging shows signs of opening.
