Konica KM1600 UH-HA820 Printhead

The Konica KM1600 UH-HA820 printhead is a high-resolution piezoelectric printhead designed for use in DGI FabriJet FT-1604X and FT-3204X textile printers. It combines two Konica KM800 printheads into a single unit. Here are its key specifications:

Konica KM1600 UH-HA820 Printhead Key specifications:

• Technology: Piezo Electric

• Native Resolution: 600 dpi

• Nominal Drop Size: 11 pico liters

• Adjustable Drop Size Range: 3 to 14 pico liters

• Maximum Frequency: 30 kHz

• Ink Compatibility: Aqueous-based and solvent inks

• Print Width: approximately 56.4 mm

• Number of Nozzles: 1600 (double that of KM800)

• Grayscale Level: 4

• Origin: Japan

This printhead is built for robust, high-speed, and precise inkjet printing suited especially for textile printers like the DGI FabriJet series. It supports multiple ink types and offers fine droplet control for detailed and vibrant prints.​

The Konica KM1600 UH-HA820 Printhead is well-suited for demanding, high-resolution textile printing with fine droplet control and fast jetting frequency, offering durability and consistent print quality for industrial use.
