Konica Minolta KM512 LH 42PL Industrial Inkjet Printhead – New in Original Factory Packaging

The Konica Minolta KM512 LH is a robust, shear-mode, piezo on-demand industrial printhead designed for high-speed, high-reliability printing with oil-based, solvent, and UV-curable inks. The “LH” variant includes an integrated heater (up to 55 °C), making it especially suitable for high-viscosity UV inks that require temperature control to maintain optimal viscosity at the nozzle.

With 512 nozzles arranged in two staggered lines (256 × 2) and a native resolution of 360 dpi, the KM512 LH delivers consistent drop placement and strong coverage for wide-format graphics, industrial marking, packaging, and custom inkjet systems. Its compact, winged mechanical design simplifies precise multi-head alignment in production printers.

This listing is for one new, factory-sealed KM512 LH printhead in original Konica Minolta packaging.

Technical Specifications

• Technology: 3-cycle, on-demand piezo electric (shear mode)
• Nozzles: 512 total (256 × 2 rows)
• Channel Resolution: 360 dpi (70.5 µm pitch; 141 µm × 2 rows)
• Drop Volume: 42 pL (± ~3 pL typical)
• Firing Frequency: up to 7.6 kHz
• Print Width: 36.1 mm (approx. 1.42 inches)
• Drop Velocity: approx. 6.0 ± 0.5 m/s (test condition)
• Integrated Heater: Yes, rated up to 55 °C for UV/high-viscosity inks
• Drive Mode: Binary (on/off)
• Ink Types: Oil-based, solvent, UV (high viscosity)
• Dimensions (approx.): 67 mm (W) × 40 mm (D) × 63 mm (H)
• Weight: under 95 g (printhead only)
• Specifications are based on Konica Minolta KM512 series documentation and may vary slightly by production batch.

What’s Included

• 1 × Konica Minolta KM512 LH 42PL industrial inkjet printhead
• Original factory packaging (sealed)
• No cables, driver boards, ink systems, or additional accessories are included unless explicitly stated.

Compatibility Disclaimer

Important – Please Read Before Buying

• The KM512 LH is used in many OEM and integrator-built wide-format, UV flatbed, solvent, and industrial inkjet printers.
• Compatibility depends on your printer’s mainboard, waveform, ink system, firmware, and mechanical mounting.
• This printhead is not automatically compatible with every printer that uses a “KM512” series head; there are different variants (LN, LH, MN, MH, etc.) with different ink and heater specifications.

Buyer is responsible for verifying compatibility with their specific printer model and controller before purchase. If you are unsure, please message us with:

• Printer brand and model
• Current printhead model number (as printed on the head or in the manual)
• Ink type you are using (UV / solvent / oil-based)
• We will do our best to advise, but final compatibility verification rests with the buyer.

Condition & Packaging

• Condition: New
• Packaging: Factory sealed in original Konica Minolta packaging
• Handling: Do not open the printhead package until you are ready to install. Avoid touching the nozzle plate or electrical contacts. Store in a cool, dry place, away from direct sunlight and extreme temperatures.

Shipping

• Handling Time: We ship within [1–2] business days after cleared payment.
• Shipping Service: Shipped via [your preferred carrier, e.g., UPS / FedEx / DHL / USPS] with tracking.
• Packaging: Printhead is packed securely with protective materials to prevent damage during transit.
• Combined Shipping: We offer combined shipping on multiple items. Please message us before payment for a revised invoice if you are purchasing more than one item.
• International Shipping: Available to [list countries/regions or “most countries”]. Import duties, taxes, and customs charges are the buyer’s responsibility and are not included in the item price or shipping cost.

Returns

• Return Window: Returns accepted within [14 / 30] days of delivery.
• Condition for Return: Item must be unused, unopened, and in original factory-sealed packaging. Once the printhead packaging is opened or the head is installed, it cannot be returned unless it is proven to be dead on arrival (DOA) and not damaged by improper handling or installation.
• Return Shipping: Buyer pays return shipping unless the item is not as described or is DOA and confirmed by us.
• Refund: Refund issued for the item price once the returned item is received and inspected. Original shipping charges are non-refundable unless the return is due to our error.

Please contact us before initiating a return so we can provide instructions and, if applicable, an RMA number.

Warranty

• Seller Warranty: This item is sold as new, factory sealed. We do not provide an additional seller warranty beyond the return policy described above.
• Manufacturer Warranty: Any manufacturer warranty is subject to Konica Minolta’s policies and may require proof of purchase from an authorized distributor. We are [an authorized / not an authorized] Konica Minolta distributor – please message us if you have specific warranty questions.
• DOA Policy: If the printhead is confirmed dead on arrival (no electrical shorts caused by the user, proper installation, and compatible electronics), we will replace or refund according to our return policy. Damage caused by incorrect installation, incompatible electronics, wrong ink, static discharge, or physical damage is not covered.

Important Handling & Safety Notes

• Do not open the printhead until you are ready to install it.
• Follow your printer manufacturer’s installation and priming procedures exactly.
• Ensure your ink system, temperature settings, and waveforms are configured for the KM512 LH 42PL model.
• Avoid touching the nozzle plate, filter, or electrical contacts.
• Store in a clean, dry environment, away from dust, direct sunlight, and temperature extremes.
