The Toshiba CF1BXL Printhead is an industrial, drop-on-demand piezo inkjet printhead featuring an ink-recirculating architecture across all channels. Designed for extra-large drop volumes up to 180 pL, it supports UV-curing and oil-based fluids for high-opacity coatings, thick ink layers, and functional fluid applications.
Item specifics
- Technology: Piezo Inkjet Drop-on-Demand (with channel-level recirculation)
- Nozzle Count: 636 nozzles
- Native Resolution: 300 dpi
- Print Width: 53.7 mm
- Drop Size Volume: 36 pL to 180 pL (Extra-Large drop capability)
- Max Dot Frequency: 4.8 kHz
- Fluid Compatibility: UV-curing and oil-based inks / functional fluids
- Country/Origin: Japan (Manufactured at official Toshiba Tec facility)
Compatible printer models
The Toshiba CF1BXL belongs to the broader CF1 series architecture. However, unlike the standard variant, the "XL" designation signifies a highly specialized, extra-large drop volume configuration (36 pL to 180 pL).
- Mimaki UJF-7151 Plus
- Mimaki UJF-7151 Plus II
Important Notice
To prevent costly buyer return requests, it is critical to explicitly state what this head does NOT fit:
Standard Mimaki UJF-7151 Plus Printers
Stock Mimaki machines use the standard CF1B or CF1BL head. This CF1BXL head will NOT work in a stock Mimaki printer unless your machine was specifically customized or retrofitted from the factory for heavy 3D textured/varnish printing.
Direct Replacement for CF1B, CF1BL, or CF1L
It has the same shape and plugs, but the internal electronics are different. If your old printhead does not explicitly have CF1BXL printed on it, this head will cause severe misfiring and error codes.
Older Toshiba Systems (CA4 / CE4 / CE4W)
This head is completely incompatible with older-generation Toshiba printers. The physical size, wiring, and ink tubes will not fit.
Water-Based (Aqueous) or Solvent Ink Printers
This head is strictly designed for UV-curable and oil-based inks only. Water or solvent inks will permanently destroy the internal seals.
Do not buy this printhead based on looks alone. It is a highly specialized "XL" (Extra-Large) model. It will NOT work as a simple drop-in replacement for other models.
The Difference: Toshiba CF1BXL vs. CF1BL
While these two printheads look identical on the outside, their internal software tuning and ink delivery are completely different:
- Toshiba CF1BL (Standard): Fires smaller ink droplets (57 to 80 pL). Used for standard graphics and packaging.
- Toshiba CF1BXL (This Item): Fires massive ink droplets (36 to 180 pL). Used for ultra-thick coatings, textured varnishes, and 3D/Braille printing.
- Because the ink droplet sizes and voltages are completely different, a printer programmed for a CF1BL cannot run this CF1BXL head without advanced software and waveform reprogramming.
Not sure? Send us a quick photo of your current printhead's factory part code sticker before buying, and we will verify the fit for you!
